CPU1208-10
Classification:
Key words:
Chip model: Fudan FM1208-10 (7KCPU 1K M1 card) or 1208-9(8KCPU)
Product Details
Chip model: Fudan FM1208-10 (7KCPU 1K M1 card) or 1208-9(8KCPU)
Features of FM1208 card
High security, compatibility, wide application, scalability.
FM1208 card technical parameters
Protocol standard: ISO/IEC14443-A MCU instruction compatible with 8051
Working frequency: 13.56Mhz
Data transfer rate: 106Kbit/s
Program memory: 32KX8bitROM
Data memory: 8Kx8bitROM (5K for FM1204) 256X8bitiRAM 384x8bitRAM
Number of erases:> 100000
Data retention:>10 years
FM1208 card production process
Optional materials: ordinary PVC, high temperature resistant materials (ABS, PET), transparent materials
Packaging process: ultrasonic automatic planting line/automatic welding
Standard card size: 85.5 × 54mm (size and thickness can be customized according to customer needs)
FM1208 Card Optional Manufacturing Process
1. Offset printing, silk screen printing, gold bottom, silver bottom, UV raised,
2. smooth surface, matte surface, frosted surface, UV varnish,
3. Convex code (large | small | bronzing | silver), flat code (black | gold | silver | red | blue | white), spray code, laser engraving code,
4. Add magnetic stripe, signature strip and hot plate (gold/silver/laser gold/laser silver/black gold/red gold/plain gold)
FM1208 card applications
City bus, all-in-one card, highway card, small consumption card, campus card, financial payment electronic wallet, identity authentication.
